Standard Mesh Type A-EC

Mesh

Manufactured to BS 4483 from cold reduced wire which complies with BS 4482. Each wire intersection is resistance welded using electronically controlled techniques. Standard Mesh available in any combination of bar sizes from 8mm to 16mm.

Clear
Category:
Type Ø Dimensions LxB (mm) Centres (mm) Weight Kg/piece Pieces/ Bundle Weight Kg/ Bundle
A142EC 6-6 4800×2400 200-200 23.98 46 1.103
A193EC 7-7 4800×2400 200-200 32.62 34 1.109
A252EC 8-8 4800X2400 200-200 42.66 28 1.195
A393EC 10-10 4800X2400 200-200 66.64 18 1.199
